SPECIFICATIONS | |||
---|---|---|---|
Power Source | AC 100 V | Snap Switch | Toggle |
Frequency | 50Hz, 60Hz | ||
Motor | 25w geared motor | Nut Size | M4, 5, 6, 8, 10, 12, |
Air Pressure | 4 kg/cm2 | ||
Hopper | SUS304 | Cap. of Hopper | M6 6000 |
Stainless Steel Plate | SUS304 Hard chrome-plated on the side | Joint | 1/8 one-touch |
Cylinder | Stroke 200mm | Control | Sequencer |
Cylinder switch | MAX 120VAC 50VDC | Air consumption | 1.1NL/1stroke |
